Lopolight 225 Masthead Light - Single - Silver Housing - Vertical Mount [201-010]

Lopolight 225 Masthead Light – Single – Silver Housing – Vertical Mount [201-010]

Original price was: $358.79.Current price is: $217.64.

SKU: 201-010-LOP Category:

Description

225° Masthead Light – Single – Silver Housing – Vertical Mount

This LED navigation light consists of a single high-power LED that produces light in the specified angle utilizing a special designed PMMA light guide.

The precision machined 6082 aluminium housing with an anodized surface makes the light a rugged and durable housing for the LEDs and electronics contained within.

The interior is completely filled with a special potting resin making it water- and vibration proof.

Produced in our in-house manufacturing facility to meet and exceed exacting standards such as EN14744 and UL1104, under a quality management system continuously surveyed by Lloyds Register Quality Assurance.

Each light is subjected to final testing for a minimum of 16 hours of continuous operation bringing the total test time beyond 24 hours. This navigation light is in compliance with the following standards:

  • COLREG72
  • EN14744
  • IEC 60945
  • USCG (UL1104)

Specifications:

  • Vessel size: <12m (<39.4’)
  • Visibility:>2 nautical miles
  • Intensity:>5,4cd
  • Power consumption: 2,5 Watt; Current: 0,21A @12 VDC – 0,10A @24 VDC
  • Operating voltage: 10 – 32 VDC
  • Number of LEDs: 2
  • Light colour: White
  • Operating temperature: -25°C to +55°C
  • IP rating: IP68
  • Mounting: Vertical

Specifications:

  • Housing: Silver
  • Lens Color: White
  • Visible Range (Miles): 2nm
  • Voltage – Input Range (Volts): 10-32v
  • LED: Yes
  • Box Dimensions: 4″H x 4″W x 5″L WT: 0.95 lbs
  • UPC: 879343010201
